30" INDUSTRIAL GRADE OSCILLATING

PEDESTAL FAN WITH WHEELS

Model 3138

Rev. E 8/10 1

5084445

GENERAL SAFETY INFORMATION

1. Read all instructions before using Fan.

2. Make certain that the power source conforms to the electri-

cal requirements of the Fan.

3. Use this Fan only as described in this manual. Any other use not

recommended by the manufacturer may cause ﬁre, electrical

shock, or injury to persons.

4. To reduce the risk of personal injury and electric shock, the

Fan should not be played with or placed where small children

can reach it.

5. Unplug power cord before servicing, or moving the Fan.

WARNING: DO NOT DEPEND UPON THE ON-OFF SWITCH

AS THE SOLE MEANS OF DISCONNECTING POWER WHEN

INSTALLING OR SERVICING THE FAN. ALWAYS UNPLUG THE

POWER CORD.

6. This Fan must NOT be used in potentially dangerous

locations such as ﬂammable, explosive, chemical-laden

or wet atmospheres.

7. DO NOT use Fan in or near a window. Rain may create an

electrical hazard.

8. Completely reassemble Fan, according to instructions,

before reconnecting to power supply.

9. The power cord is equipped with a three-prong grounded

plug that must be inserted into a matching receptacle. Under

no circumstances should the grounding prong be cut off the

plug. Where a two-prong wall receptacle is encountered,

it must be replaced with a properly grounded three-prong

receptacle installed in accordance with the National Electrical

Code (NEC) and all applicable local codes and ordinances.

This work must be done only by a qualiﬁed electrician, using

copper wire only.

WARNING: USE OF A THREE-PRONG TO TWO-PRONG

ADAPTER IS NOT RECOMMENDED. IMPROPER CONNECTION

MAY CREATE THE RISK OF ELECTROCUTION. USE OF SUCH

ADAPTER IS NOT PERMITTED IN CANADA.

10. Where possible, avoid the use of extension cords. If they must

be used, minimize the risk of overheating by ensuring that they

are UL listed. Never use a single extension cord to operate

more than one Fan.

11. NEVER operate any Fan with a damaged cord or plug or after

the Fan malfunctions, has been dropped or damaged in any

manner.

12. Do not insert or allow ﬁngers or foreign objects to enter any

ventilation or exhaust opening as it may cause an electric shock

or ﬁre, or damage the Fan. Do not block or tamper with the Fan

in any manner while it is in operation.

13.Always place the Fan on a stable, ﬂat, level surface when

operating, to avoid the chance of the Fan overturning. Locate

the Power Cord so the Fan or other objects are not resting on it.

Do not run cord under carpeting. Do not cover cord with throw

rugs, runners, or similar coverings. Do not route cord under

furniture or appliances. Arrange cord away from trafﬁc area and

where it will not be tripped over.

14.This Fan is not intended for use in wet or damp locations.

Never locate a Fan where it may fall into a bathtub or other

water container.

15. Do not use Fan outdoors.

16.This Fan is not suitable for use in agricultural facilities including

areas where livestock, poultry or other animals are conﬁned.

Please refer to National Electric Code (NEC) Article 547-7

(2008), or applicable state or local codes or standards relating

to electrical requirements for Agricultural Buildings. THIS FAN

DOES NOT MEET THE REQUIREMENTS OF NEC ARTICLE

547-7 (2008).

17.This Fan is not suitable for use in hazardous locations. Please

refer to National Electric Code (NEC) Article 500 or applicable

state or local codes or standards relating to electrical

requirements for Hazardous locations. THIS FAN DOES NOT

MEET THE REQUIREMENTS OF NEC ARTICLE 500 (2008).

WARNING: REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK

– DO NOT USE THIS FAN WITH ANY SOLID STATE SPEED

CONTROL DEVICES.

CAUTION: BECAUSE OF THE SIZE AND WEIGHT OF THIS

FAN, MAKE SURE ALL PARTS ARE COMPLETELY ASSEMBLED

ACCORDING TO INSTRUCTIONS. FAILURE TO DO SO COULD

RESULT IN FAN COMING APART DURING OPERATION AND/OR

PERSONAL INJURY.

SAVE THESE INSTRUCTIONS

INCLUDED WITH THIS FAN:

(1) 3 Speed, Oscillating Motor Assembly

(1) Column Assembly

(1) Base

(1) Blade

(1) Front Grill

(1) Rear Grill

(1) Hardware Bag

(1) Motor Hardware Bag

(1) Wheel Kit Bag

(1) Instruction Sheet

READ AND SAVE THESE INSTRUCTIONS

READ CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE, INSTALL, OPERATE OR MAINTAIN THE PRODUCT DESCRIBED.

PROTECT YOURSELF AND OTHERS BY OBSERVING ALL SAFETY INFORMATION. FAILURE TO COMPLY WITH

INSTRUCTIONS COULD RESULT IN PERSONAL INJURY AND/OR PROPERTY DAMAGE!

RETAIN INSTRUCTIONS FOR FUTURE REFERENCE.
